D-BOX+

The Dangerous D-BOX+ is a ground-up dramatic redesign of the award-winning controller and summing mixer that provided countless studios the superior sound and versatile control of an analog mixer, all in just one rack space. The newly designed 8-channel summing mixer and D-A stereo converter provide Dangerous Music’s bold and clear sound, while newly added features like Bluetooth connectivity and an app for remote control of all major functions unleash a cutting edge feature set that puts the D-BOX+ far ahead of the competition. As with all Dangerous Music products, the D-BOX+ is proudly made to exacting audiophile standards in the USA.

TOTAL CONTROL

Like a large console’s center section, the D-BOX+ provides elaborate routing and switching of your studio’s inputs and outputs, both analog and digital. At the push of a button, you can select from five input sources: analog stereo, the onboard analog summing mixer, USB, AES/SPDIF and—brand new for the D-BOX+—a wireless Bluetooth stream from any Bluetooth-enabled device. Outputs include three stereo speaker ports, and these can be programmed to be mono and/or to include a subwoofer. Further, you can use output 3 as source for an independent sub with individual level and mute control.

VERSATILE MONITORING OF MULTIPLE SOURCES

Any studio situation, but especially tracking sessions, call for independent monitor routing for artist and engineer. With the D-BOX+ you have two totally independent monitoring sections: Control Room and Headphones. With the simple push of a button, you can assign any of the five input sources to either of these monitoring paths, making what would otherwise be elaborate patches into instant choices. Want to check on your monitors what your artist is hearing in their headphones? Seamless source switching is simple.

REMOTE CONTROL VIA BLUETOOTH AND THE D-BOX+ APP

Using the new D-BOX+ Bluetooth app, on any current phone, tablet, or computer, you are no longer bound to your chair when you need control your studio. All major functions of the D-BOX+ show up in the highly intuitive and rock solid program, providing limitless new solutions to age-old studio problems. Want to listen to an artist’s instrument in the live room while switching monitoring sources in their headphones? No problem. Want to give a couch-bound producer control over the talkback mic through their phone? Simple. Want to listen to your mixes from the hallway while still swapping monitors or switching a sub in and out? You got it. If you can dream it up, the D-BOX+ app will deliver.

TWO POTENT HEADPHONE AMPS

A great session requires a great headphone mix, and a great headphone mix requires a great headphone amp. With the D-BOX+ you get two of them. These potent amps are so clean, powerful, and accurate that many engineers use them exclusively for fine-grained quality control listening right before delivering a record to market. With the easy yet elaborate routing capabilities of the D-BOX+, you’ll be able to send any source to either headphone amp from either the front panel or remotely from within the D-BOX+ app.

ROCK SOLID USB CONNECTIVITY FOR WINDOWS AND MAC

USB audio connectivity has come a long way over the past decade, and Dangerous has been at the forefront of its development the entire time. With the D-BOX+ you not only get an ultra-fast, low-latency USB port, you also get the latest driverless connectivity on macOS and flawless driver support on current Windows computers. Say goodbye to fussing around with software just to get up and running, and say hello to plug-and-play connectivity.

SUMMING SECTION

Frequency Response Flat within 0.1dB from 10Hz to 50kHz
THD+N @ +4dBu 0.0019%
IMD 0.0020%
Crosstalk Rejection >114dB @ 1kHz
Noise floor @ unity gain 22Hz to 22kHz <-90dBu Maximum Input Level +27dBu

SELECTED LINE OUTPUT

Frequency Response Flat within 0.5dB from 10Hz to 50kHz
THD+N @ +4dBu 0.0027%
IMD 0.0027%
Crosstalk Rejection >110dB @ 1kHz
Noise Floor 22Hz to 22kHz <-89dBu Maximum Input Level +26dBu

MONITOR SECTION

Frequency Response Flat within 0.5dB from 10Hz to 50kHz
THD+N @ +4dBu 0.0049%
IMD 0.0090%
Crosstalk Rejection >106dB @ 1kHz
Volume off signal rejection >120dB
Noise floor at unity gain 22Hz to 22kHz <-90dBu

USB & AES DACS, MEASURED AT 96KHZ SAMPLE RATE:

Frequency Response Flat within 0.5dB from 10Hz to 30kHz
THD+N @ -14dBfs 0.0027%
Crosstalk Rejection >115dB @ 1kHz
Dynamic Range >106dB

HEADPHONE AMPS:

4 ohm minimum load per amplifier (6-8 pairs of typical studio dynamic headphones)
Power Output 3 Watts / Channel
THD+N 0.0066%
Crosstalk Rejection >100dB
